Desktop Small Precision Three-roller Calendering Auxiliary Machine

Desktop small precision three-roller calendering auxiliary machine 01 The desktop small precision three-roller calendering auxiliary machine is composed of a calendering system, a traction system, a winding system, an edge trimming system and a measurement and control system, which can realize...

Send Inquiry

Description

Desktop small precision three-roller calendering auxiliary machine

The desktop small precision three-roller calendering auxiliary machine is composed of a calendering system, a traction system, a winding system, an edge trimming system and a measurement and control system, which can realize functions such as polymer calendering, traction, edge trimming and winding.

Application

 Calendering molding experiment of polymer materials
 Calendering production process research and parameter optimization
 Calendering performance test of new materials

High-strength European standard integrated frame, light, beautiful and durable
304 stainless steel desktop, practical and beautiful.

product-3024-3624

product-3024-4032

Product parameter

Applicable materials	PE/PP/PS/EVA/PC and composite materials, etc.
Product thickness	0.1-0.6mm
Roller width	350mm
Gap between rollers	0-10mm
Line speed	0-10m/min
Working voltage	3φ380VAC±10%, 1φ220VAC±10%, 50Hz
Rated power	About 10kW (including temperature cycle controller)
Length × width × height	1200mm×1030mm×1630mm
Machine weight	About 600kg
