High-Performance Multi-Functional Three-Layer Co-Extrusion Film Blowing Machine
High-performance multi-Functional three-layer co-extrusion film blowing machine manufactures advanced 3-layer coextrusion blown film lines for high-barrier packaging, agricultural & industrial films. Get high output, precision control.
Description
Why Choose Us?
16 Years Experience
Professional manufacturer of new polymer lab & pilot machine
Customization
Deep customization of polymer lab & pilot machine
Transport
Fast delivery in cooperation with several logistics companies
Favorable Price
Customers can enjoy the company's long-term technical advisory services
Product Feature
Wind Ring
Aluminum alloy DC vector slip rings, stable, energy-efficient, and low-noise.
servo motors
High-level servo motors and dedicated servo drives.
Traction Assembly
Pneumatic clamping mechanism with cantilever design enables one-handed film feeding.
A-frame
Anti-static, easy-to-adjust tension control.
Product Composition
Precision single-screw extruder:Servo motor, dedicated servo drive
Screen changer:Quick-Connect Design, 304 Stainless Steel
Three-layer co-extruded blown film die head: ABC three-layer spiral flow channels, layer ratio: 1:1:1.
Wind Ring: Aluminum alloy DC vector wind ring, stable, energy-efficient, low noise.
Steady Bubble Level: Digital motor, continuously adjustable, height adjustable from 0 to 380mm.
A-frame: Anti-static, with adjustable angle for easy operation.
Tension assembly: Steel rollers feature hard chrome plating
and mirror polishing; rubber rollers are covered
with silicone and treated with an anti-adhesive coating.
Lifting assembly :Aluminum alloy silent lifting mechanism.
Safety protection device: The control panel is equipped with an
emergency stop button to ensure operational safety.
Control System: 10-inch touchscreen providing operation of all systems including extrusion, lifting, bubble adjustment, traction, and winding systems. Displays temperature and pressure curves, and allows querying of fault alarm information.
Technical Specifications Table
|
Applicable materials |
PE, POF, PVC, LDPE, LLDPE, etc. |
|
Screw diameter |
φ20mm |
|
Aspect ratio |
28 |
|
Screw speed |
0-120rpm |
|
Die diameter |
45mm |
|
Number of co-extrusion layers |
3 |
|
Maximum folding diameter |
200mm |
|
Product specifications |
0.02-0.15mm |
|
Roller width |
220mm |
|
Line speed |
0-10m/min |
|
Pressure measurement range |
0-50MPa |
|
Pressure measurement accuracy |
0.5%FS |
|
Extrusion temperature control range |
Room temperature -350℃ |
|
Temperature control accuracy |
±1℃ |
|
Working power |
Three-phase five-wire 380VAC±10%, 50Hz |
|
Working air source |
Compressed air, 6-8bar |
|
Cooling water |
Soft water at room temperature, supply and return pressure difference: 2.5-4.0bar |
|
Working environment |
Ambient temperature: 10-40℃; Relative humidity: ≤ 80%, no condensation |
|
Rated power |
About 30kW |
|
Length × width × height |
2810mm×2130mm×2015mm |
|
Machine weight |
About 1200kg |
