Lab 3D Filament Extrusion Line
Lab 3D Filament Extrusion Line is composed of extruder, wire mold, water tank cooling system, storage line system, traction system, winding system, etc
Description
Plastic film forming functional lab 3d filament extrusion line
1. Product description
It is used for the polymer wire extrusion molding test.
The development of winding neat rows.
Process optimization, cost control and small-scale production
.
Plastic film forming functional lab 3d filament extrusion line application：
● Using SIEMENS touch operation, real-time display of the running state, alarm information and system parameters.
● PID temperature control, the accuracy up to ±1℃.
● The traction unit using imported servo motor drive and is composed of the closed-loop control system with diameter measuring instrument, can quickly response to a host of speed change，which can quickly respond to the change of the speed of the extruder.
● Using imported servo motor drive, to ensure the tension balance, rolling smooth and tidy.
2.Technical Parameters
Item | Unit | SESIH-20/28 |
Screw Diameter | mm | 20 |
L/D ratio | mm | 28 |
Screw speed | rpm | 94 |
Roll speed | m/min | 10 |
Max. output | Kg/h | 3 |
Material size | mm | Φ1.75 |
Material.accuracy | mm | ±0.05 |
Main motor power | kW | 1.5 |
Total power | kW | 5 |
Size (L×W×H) | mm | 2080×780×1320 |
3．About us
Guangzhou Putong, located in Guangzhou, is a high-tech enterprise specializing in the manufacture and development of polymer material rheological property tester and polymer material processing and molding experimental equipment.
4．FAQ
1 Q:After machine arrival, what will be the service for installation and training?
A:If you are close to our local agent, you can contact them directly for spot service.Usually we will send our engineer for overseas spot service to finish installation of the machine and operation training, which will take extra cost like air-ticket and accomodation.
2 Q:Can you offer training service?
A: Yes, we offer free-training service.
3 Q: Can I get some free accessories if I buy the machine?
A: We offer the components with favorable price and perdurable maintenance.
4 Q: After an order is placed, when to deliver?
A: Generally about 10~28 days, if we have inventory, we can arrange shipment within 3 days, please note that the length of our production depends on the specifi product and quality of the product
Hot Tags: lab 3D filament extrusion line, China, suppliers, manufacturers, factory, price, for sale, PEEK Filament Manufacture Line, Small 3D Filament Extrusion Line for Lab, 3D Filament Extruder, PLA ABS Filament Production Line, 3D Filament Extrusion Line, Lab 3D Filament Extrusion Line
