Lab Mixer Torque Rheometer

Name: China Lab Mixer Torque Rheometer Suppliers, Manufacturers - Factory Direct Price - POTOP
Brand: POTOP
SKU: 219303471

Specifically designed for the thermoplastics resin industry. Torque Rheometer is well established as a valuable formulation development, formulation research and production quality control tool.

Send Inquiry

Description

Lab Mixer Torque Rheometer

1.Product Introduction

It is the ideal equipment to study the flow, plasticisation, thermal and shear stability of materials. The rheometer provides a dynamic measurement method closer to the actual processing, which can continuously, accurately and reliably determine the rheological properties of materials in a situation similar to the actual processing, such as the mixing of multi-component materials, crosslinking curing of thermosetting resins, vulcanisation of elastomers, the dynamic stability of the material, and the screw speed Influence on the processing performance of the system, etc.

product-1-1

mixer torque rheometer

2.Product Parameter

	Unit	RTOI-06/02 RTOI-20/10 RTOI-30/10
Chamber volume	cm3	55/200/300
Revolution speed	rpm	200
Rotor speed ratio		2:3
Torque measuring range	Nm	0-200
Torque tolerance		0.5 % F.S
Max. temp.	℃	350
Temp. measuring accuracy	℃	±1
Heating/cooling method		Electrical heating / Air cooling
Driving power	kW	3
Total power	kW	4.5
Total weight	kg	300
Size (L×W×H)	mm	1250×690×1350

3.Product Feature

1. Plasticizer absorption performance test of PVC dry mixture.

2. Thermal and shear stability test of thermoplastic materials.

3. Determination of XLPE cross-linked ethylene cross-linking characteristics.

4.Research on flow and curing behavior of crosslinked polymer.

5. Formulation design of inorganic powder sintering materials such as metals and ceramics.

4.Product Application

1. Polymer material formulation design;

2. Raw material performance and quality inspection;

3. PVC melting characteristics test;

4. Test the thermal and shear stability of thermoplastic materials;

5. Study on the flow and curing behavior of cross-linked polymers;

6. Metal, ceramic and other inorganic powder sintering molding material formula design.

product-1-1

5.Products Working Principle

Torque rheometer

6.Products Use Steps

Torque rheometer operating steps

7.Rotors of torque rheometer

Torque Rheometer Rotors

Torque Rheometer Curve

8.About Us

POTOP's mechanical engineering and polymer material processing and moulding theories are extensive, and they are integrated with electrical, electronic, and software technology to produce high-end polymer material experimental and pilot production equipment for customers.
