Lab Upright Biaxially Oriented Film Stretcher
Guangzhou POTOP has successfully developed Lab Upright Biaxially Oriented Film stretcher instrument, suitable for PP, PE materials,PET, PPS,PVDF,PEEK,PI and so on.
Description
Products Description
The Lab Upright Biaxially Oriented Film stretcher can make the thickness of the bidirectional stretch film material less than 0.2-2mm, as small as 95 x95mm thick film sample, according to the required tensile ratio, at the appropriate temperature and time for the film tensile test, for the laboratory for physical and chemical testing analysis, according to the sample film properties, to determine a wide variety of additives and formulations. Then applied to production line, can greatly reduce the cost of trial production.
The film biaxial stretching instrument consists of a clamping assembly, a stretching assembly, a stretching mechanism moving assembly, a hot oven assembly, a pneumatic air curtain assembly and an electrical control system.
The film biaxial stretching instrument can perform a stretching test on a film sample of a certain size at the required stretching ratio at a suitable temperature and time, and the test data can be used for analysis by researchers.
The film biaxial stretching instrument developed by Guangzhou Putong is a digital engineering instrument with good repeatability and accurate data; it can be operated offline, equivalent to a production line; it can improve experimental efficiency and shorten product development cycle.
Our Advantage
Products Application
➢ New product research and development in the high-end thin film field
➢ Laboratory test and analysis of the physical properties and chemical properties of the new material film molding
➢ High-end thin-film formula design
➢ Process Research and Parameter Optimizatio
Products Parameters
|
Applicable materials |
PE, PP, PET, PTFE, PVDF, etc |
|
Sample thickness |
0.02-1.5mm |
|
Sample size |
Min 80*80mm, max 100*100 mm |
|
Stretching ratio |
4:4 |
|
Stretching speed |
0-300mm /s ( adjustable) |
|
Stretching force |
1000 Nm |
|
service temperature |
Room temperature -250℃ |
|
Temperature control accuracy |
±2℃ |
|
Stretch motor power |
1.0 kW |
|
working voltage |
3 φ380V AC±10%, 1 φ220VAC±10%, 50Hz |
|
power rating |
About 22kW |
|
L*W*H |
2040mm×1050mm×1680mm |
|
weight |
About 1000 kg |
