Lab Torque Rheometer For Rheological Testing

Lab torque rheometer for rheological testing is mainly composed of transmission box components, operation box components, mixer components, power components, console components, frame components and software operation components. All parameter settings, system control, data recording, etc. are operated/displayed through the computer equipped with measurement and control software.

1. The integrated design of the fuselage is more compact than the workstation, and it is more convenient to use and maintain.

2. The rotor is driven by a branded servo motor with high running precision and good speed control.

3. High-strength alloy standard internal mixing rotor, the shape of the rotor can be selected according to the material and process

4. Electric heating and PID temperature control mode, fast heating speed and good temperature control.

5. Automatic timing function of mixing time.

6. High-strength welded frame, compact structure, stable operation.

1. Composite formulation design

2. Raw material performance, quality inspection

3. PVC melting characteristics test

4. Plasticizer absorption performance test of PVC dry mix

5. Thermal and shear stability testing of thermoplastic materials

6. Study on Flow and Curing Behavior of Crosslinked Polymers

7. Polymer Processing Process Design and Optimization

8. Formulation design of inorganic powder sintering molding materials such as metals and ceramics

1. When installing the experimental platform, attention should be paid to the connection sequence of the thermal sensor and the heating power interface. The wrong connection sequence will lead to incorrect temperature control.

2. When the temperature in a certain area of the mixer or extruder is 10°C lower than the set temperature, the residual material in the equipment may not be completely melted, and rotating the motor at this time may damage the equipment. The experimental operation can only be started after the temperature and the output speed of the motor have reached the set value and stabilized.

3. The mixing device should be cleaned after each experiment, and the rotors in the mixing device should not be reversed; R to R, L to L. Remember to turn off the power.

4. After the experiment, add a small amount of lubricant, then disassemble and clean the mixer.

 Guangzhou Putong adheres to the principle of "high technology, high starting point, high quality, and high efficiency", adheres to technological progress and continuous innovation. Since its establishment, it has successively developed new products such as "fish eye" tester, color masterbatch dispersion tester, small precision extrusion casting experimental machine, small precision extrusion film blowing experimental machine, and polymer material film unidirectional/biaxial tensile experimental equipment. Many of these products have filled the domestic gap.

1.Q: After machine arrival, what will be the service for installation and training?

 A: If you are close to our local agent, you can contact them directly for spot service.Usually we will send our engineer for overseas spot service to finish installation of the machine and operation training, which will take extra cost like air-ticket and accomodation.

2.Q:Whether you can provide ON-SITE training service if we need?

 A: Yes, we can provide if it is necessary.

3.Q:can you customize the machine?

   A: We can design and manufacture all kinds of non-standard

machinery according to customers requirement. OEM is available for POTOP Products

4.Q: If the machine is broken what can I do?

   A: Free maintenance within the warranty period

   Maintenance for equipment failure caused by improper handling (appropriate cost will be collected).
