High Quality Extrusion Capillary Rheometer
The polymer melt is a pseudoplastic fluid with the flow characteristics of shear thinning. The relationship between its viscosity and the shear rate constitutes the general viscosity. Viscosity can fully characterize the fluidity of polymer melt, and the processing characteristics of polymer depend on its flow behavior
Description
High Quality Extrusion Capillary Rheometer
Application:
lPolymer extrusion capillary rheological properties test.
lPolymer extrusion and shear behavior analysis.
lPolymer processing and performance evaluation.
lPolymer resin quality inspection.
Video of High Quality Extrusion Capillary Rheometer
Packing of High Quality Extrusion Capillary Rheometer
Hot Tags: high quality extrusion capillary rheometer, China, suppliers, manufacturers, factory, price, for sale, mixer torque rheometer, Capillary and rotational rheometers, Torque Rheometer Test, Torque Rheometer system, Torque Rheometer Extruder, Extrusion Rheometer Principle
Parameters of High Quality Extrusion Capillary Rheometer
Model | RCSI-20/28 |
Applicable materials | Universal plastics |
Screw diameter | 20mm |
L/D | 28 |
Screw speed | 0-100rpm |
Capillary die dia. | 1mm、2mm |
Capillary die L/D | 1mm：10、20、30、40；2mm：10、20 |
Pressure measurement range | 0-50mpa |
Pressure measurement accuracy | 0.5%f.s |
Weight accuracy | ±0.1g |
Heating/cooling method | Electric Heating/Fan cooling |
Operating temperature | Room temperature-350°C |
Temperature accuracy | ±1℃ |
Main motor power | 3kw |
Control | SIEMENS PLC |
Working voltage | Three-phase 380VAC±10%,Single-phase 220VAC±10%,50Hz |
Rated power | Approx. 9kW |
Lx W x H | 1255mm×1005mm×1000mm |
Weight | Approx.450kg |
