Split Small Precision Three-screw Extrusion Granulation Line For General Plastics, Engineering Resins Etc.

Split small precision three-screw extrusion granulation line Product Introduction The split small precision three-screw extrusion granulation line consists of a split small precision three-screw extruder, a screen changer, a granulation mold, a cooling water tank, an air drying device and a...

Send Inquiry

Description

Split small precision three-screw extrusion granulation line

Product Introduction

The split small precision three-screw extrusion granulation line consists of a split small precision three-screw extruder, a screen changer, a granulation mold, a cooling water tank, an air drying device and a small precision granulator.

The split small precision three-screw extruder adopts a split barrel and a parallel meshing co-directional three-structure screw. The screw elements can be recombined according to the material characteristics to achieve the mixing of materials with different characteristics and improve the mixing and mixing effect. It is mainly used for filling, blending, modification, addition, chlorination, polypropylene and super absorbent resin processing of rubber and plastic and engineering resins.

Product Performance

Servo motor drive, stepless and precise speed regulation, stable plasticization, good consistency,
Building block screw structure, can be combined according to the needs of experimental process needs.

Split barrel, quick-open head, screen changer, faster material cleaning,
Compact integrated vacuum exhaust and cooling system.

Computer-based measurement and control system and friendly operation interface, easy to operate and more powerful.

Real-time measurement and graphic display of important data such as extrusion system, convenient observation.
Optional melt pump, can achieve precise and high-pressure extrusion

product-5184-3456

product-3456-5184

Applicable materials	General plastics, engineering resins, etc.
Screw diameter	16mm
Screw aspect ratio	40
Screw speed	0-400rpm
Pressure measurement range	0-50MPa
Pressure measurement accuracy	0.5%FS
Temperature control range	Room temperature -350℃
Temperature control accuracy	±1℃
Number of strands	2 bars
Cutting length	3±0.2mm
Cutting diameter	1-4mm
Cutter speed	0-800rpm
Working voltage	3φ380VAC±10%, 1φ220VAC±10%, 50Hz
Rated power	About 13kW
Length × width × height	4600mm×950mm×1670mm
Machine weight	About 950kg
